Roof Products SpeedDeck®
What is a SpeedDeck® Secret Fix Standing Seam Roof & Cladding System?The SpeedDeck® Standing Seam Roofing System is the original secret fix standing seam roofing. The double interlocking ribs and clips ensure strength and watertight integrity. In the 45 years since inception SpeedDeck secret fix roofing has become a worldwide proven system that offers fast, simple installation, with excellent performance and design flexibility.Secret fix standing seam built up systems have been used throughout the construction industry for many decades, maintaining a straight-forward to design, straight-forward to install principle to provide a continuous weathertight roof with no end laps. In addition there are no exposed pierce fixings, therefore creating a simple strong roof or façade system offering outstanding performance and total versatility. |
With over 45 years of pedigree and experience the SpeedDeck® secret fix standing seam metal roof system continues to offer outstanding performance, walkable, slim, contemporary and ‘cutting edge’ solutions for straight, curved, barrel vaulted and waveform roof shapes; the perfect alternative to our SpeedZip® ‘Zip-Up’ built up standing seam system.
Supplied in aluminium or steel with a vast range of colours and finishes, SpeedDeck® secret fix built up metal roof systems provide the perfect flexible solution for any designer with its ‘simple to design' principle and for the contractor ‘simple to install’ ethos. With less perimeter components, slimmer verges, wider cover width and a simple clip system with no additional zipping up or mechanical seaming, the SpeedDeck® secret fix system saves money and time and reduces the carbon footprint compared to any ‘Zip-Up’ standing seam system.
SpeedDeck® secret fix roofing and cladding systems have been used extensively throughout the industry for many decades offering bespoke, lightweight, high quality, acoustic and quick to install roofing and cladding solutions to commercial, industrial, educational, PFI, MOD, Prison Service, PFI in the new build and refurbishment construction market sectors.
Supplied in aluminium and steel and with a vast arrange of colours, and finishes SpeedDeck® secret fix roofing & facade provides a high performing, slim, simple to design and install system, driving down supply and installation costs through it efficient manufacturing and quick to install design, yet still offering a contemporary and ‘cutting edge’ standing seam solution.
We manufacture and supply 3 differing types of standing seam and secret fix built up metal roofing profiles providing you with real choice over the budget, aesthetic, material, environment and performance criteria for any new build, modular or refurbishment roofing or façade solution. SpeedDeck’s efficiency’s through design, manufacture, and installation.
All materials and finishes available in a full range of colours.
We are firmly committed to provide the highest quality products, using prime and true gauge materials to ensure the performance of all of our systems.
All systems backed with SpeedDeck’s Protector Warranty offering a system warranty including workmanship by regularly independently on-site auditing the installation of the system ensuring that quality systems are installed to provide the highest performing roof & façade systems.
SpeedDeck® 45/510 Minimum Self Curve or Site Sprung Natural Convex Radius:
0.9mm Aluminium Stucco Embossed Material – 50 / 55 Metres
0.9mm Aluminium Painted Material – 50 / 55 Metres
0.7mm Steel Material – 55 Metres
0.6mm Steel Material – 55 Metres
SpeedDeck® 45/510 Minimum Self Curve or Site Sprung Natural Concave Radius:
0.9mm Aluminium Stucco Embossed Material – 25 Metres
0.9mm Aluminium Painted Material – 25 Metres
SpeedDeck® 45/510 Minimum Smooth Curve Convex Radius:
0.9mm Aluminium Stucco Embossed Material – 10 Metres
0.9mm Aluminium Painted Material – 10 Metres
0.7mm Steel Material - 15 Metres
0.6mm Steel Material – 25 Metres
SpeedDeck® 45/510 Minimum Smooth Curve Concave Radius:
0.9mm Aluminium Stucco Embossed Material - 10 Metres
0.9mm Aluminium Painted Material - 10 Metres
SpeedDeck® 45/510 Minimum Crimp Curve Convex Radius:
0.9mm Aluminium Stucco Embossed Material – 1 Metre
0.9mm Aluminium Painted Material – 1 Metre
0.7mm Steel Material – 1 Metre
0.6mm Steel Material – 1 Metre
For all 1.2mm aluminium material curving information please call technical
For all waveform & hockey stick curving criteria please contact our technical department
Cranked SpeedDeck®
Specialist welded cranked aluminium secret fix standing seam roof sheets available all subject to transport. A cranked sheet is a bespoke fabricated SpeedDeck® roof sheet formed by welding two SpeedDeck® sheets.
Used to form a ridge on a pitched roof removing the requirement for ridge flashing and the supporting ridge components or a change of angle on either the roof or wall.
The SpeedDeck® secret fix metal roof systems are produced in ‘our state of the art’ manufacturing facilities based in Suffolk and delivered to sites throughout the Uk, and Europe. As a single source supplier of roofing & cladding / façade systems we always seek to minimise the amount of deliveries to any of your sites, reducing carbon emissions and delivery costs.
SpeedDeck® is not restricted in length by haulage as onsite roll forming of the roof sheet is encouraged to minimise the carbon impact of production by reducing deliveries on projects over 3,000m2 or where sheet lengths are over 18.5m long.
Options available to manufacture SpeedDeck® secret fix metal roofing systems:
Factory produced and delivered to site
Generally SpeedDeck® secret fix roof sheets up to 18.5m are manufactured in Suffolk and delivered to site. Although this is the norm, we have delivered to site much longer roof sheets with careful consideration of the route to the site, and the involvement of traffic management services.
If the standing seam is curved, waveform, hockey stick, tapered or cranked then our internal sales & customer service team will be delighted to advise on the best options available to you to reduce cost and the carbon impact on delivering the product to site in a timely manner.
All backed with our Protector System Warranty, providing a single source warranty for the whole system INCLUDING workmanship for up to 25 years.
 |
 |
